Magnetic TensionerMTC Series is used on coil winding machine by using permanent magnet,tension is generated to the damp wheel.The non-contact mechanism design provides stable,consistence and precision tension to the wire.Excellence for both high and normal speed winding.
|
Model |
Applied wire diamiter(mm) |
Tension scope(g) |
|
MTCSS |
φ0.03—φ0.07 |
4.0g—40g |
|
MTCS |
φ0.04—φ0.14 |
10g—120g |
|
MTCM |
φ0.08—φ0.25 |
50g—400g |
|
MTCL |
φ0.12—φ0.35 |
80g—600g |
|
MTCLL |
φ0.14—φ0.40 |
100g—800g |
