SET standard servo tension device
Tension servo device is by traditional passive wire feeding mode change initiative to send line. According to the requirements of users can choose to adjust the tension of the tension device is divided into two segments, by replacing the spring tension range can be from 1g-600g and comes with feedback tension stabilizing system, the stable tension balance can be automatically. The tension is not affected by the factors such as the speed of the winding, the cover, the pulley, etc. the tension is stable, and the adjustment is simple and convenient
Model
Applied wire diamiter（mm）
Tension scope（g.f）
SET-100
φ0.01-φ0.12
1-100
SET-200
φ0.02-φ0.17
2-200
SET-300
φ0.03-φ0.22
5-300
SET-500
φ0.05-φ0.32
20 - 500
SET-600
φ0.06-φ0.35
20-600
SET-200 Standard servo tension device：
