Servo broadcasting device is the use of active line to replace the traditional passive wire feeding way, through the motor speed control to achieve stable tension values, the product using feedback tension stabilizing system, the tension balance can be automatically.
Specifications：
|
Model |
Reference Wire Diameter Scope（mm） |
Tension Scope（g.f) |
|
ATST-101 |
φ0.02-0.12 |
1-100 |
|
ATST-501 |
φ0.08-0.30 |
20-500 |
|
ATST-102 |
φ0.15-0.45 |
30-1000 |
