Servo Tensioner(SET-B Series)
Servo tensioner unlike traditional tensioning methods,Servo tension device feed the wire automatically depends on the winding requirement.
The tension generate by servo controlled tensiner is very much more stable and consistence,compare with mechanical or magnetic type.
Tension can be set from 1.0g to 200g,it depends on the model.
Servo motor and control system are all packed within the body,SET series is solid and compact in design.It operates with DC24V electric power.
Advantages:
Simple and easy adjustment
Stable and consistence tension control
Non wire breakage
|
Model |
Applied wire diamiter(mm) |
Tension scope(g.f) |
|
SET-D-100 |
1 — 100 |
0.01 — 0.20 |
|
SET-D-200 |
1 — 200 |
0.01 — 0.20 |
